These units are SPECIAL ORDER - Delivery is 3-4 WEEKS
NOCPIX OMNI - The World's First 8K Multi-Spectrum Binocular (Thermal + Digital Day/Nightvision) with LRF
OMNI is the world's first multi-spectrum binocular featuring an 8K digital sensor with over 4× the pixel count of mainstream 4K sensors, capturing richer details for enhanced target recognition. Combining advanced digital imaging and high-performance thermal imaging in one device, it brings a comprehensive upgrade to all-day observation. Featuring a self-developed 640/384 thermal detector with NETD≤15mK, an F1.8 aperture, minimum 0.5× zoom increments, image stabilization, ranging and connectivity features, it delivers clearer imaging, more intuitive control, and greater precision in challenging conditions.
Redefine all-day Clarity
Shaping the Standard in Binocular’s Image Quality.
Higher Recognition with 8K Detail
OMNI’s 8K sensor captures over 4× the pixels of mainstream 4K sensors, preserving finer details at high magnification for more accurate target recognition.
Three scene-specific image algorithms optimize imaging across different environments, delivering clearer details in daylight, natural colors at twilight, and enhanced visibility in low-light conditions.
Faster Detection with Thermal Clarity
OMNI is equipped with Nocpix's self-developed 640/384 resolution thermal sensor with 12μm pixel pitch. The brand-new design significantly reduces noise and enhances sensitivity. Combined with NETD ≤15mK and a 50Hz frame rate, it captures temperature differences with exceptional acuity, delivering richer details, clearer targets, and more natural imagery.
Compact and Reliable
OMNI’s traditional binocular-style design provides natural, comfortable handling from the moment you pick it up. Its compact body, magnesium-alloy housing, and PVC anti-slip grip offer a secure hold and durable protection, ensuring reliable performance in demanding outdoor environments.
More Insight in One
OMNI provides distance measurement and ballistic reference data during observation, giving users more information to make faster and more accurate target assessments.
More Setups in One
The built-in tripod mount supports both handheld observation and tripod-mounted use, allowing OMNI to adapt to different scenarios from mobile scanning to stable long-duration observation.
Seamless Bluetooth Connectivity
OMNI delivers effortless wireless connection through Bluetooth, automatically linking with the Nocpix App. Share images and videos instantly without complicated setup or manual pairing.
| Specification | Details |
|---|---|
| Model | NocPix Omni L19R |
| Imaging channels | Thermal imaging and digital day/night vision |
| Thermal detector | 384 × 288 pixels; 12 μm pixel pitch |
| Thermal sensitivity | NETD ≤15 mK |
| Frame rate | Thermal: 50 Hz; digital: 50 Hz |
| Thermal objective lens | 19 mm F0.9 |
| Thermal magnification | 1.5×–12× |
| Thermal field of view | 13.8° × 10.4°; 24.3 × 18.2 m at 100 m (horizontal × vertical) |
| Thermal detection range | 1000 m for a 1.7 × 0.5 m target, P(n)=99% |
| Digital detector | 8192 × 6144 pixels; 1.2 μm pixel pitch |
| Digital objective lens | 50 mm F1.8 |
| Digital magnification | 3×–18× |
| Digital field of view | 8.8° × 6.6°; 15.4 × 11.5 m at 100 m (horizontal × vertical) |
| Digital detection range | 1000 m for a 1.7 × 0.5 m target, P(n)=99% |
| Low-light colour imaging and dynamic range | Colour imaging down to 0.001 lux; 140 dB dynamic range |
| Display | 0.5-inch AMOLED; 1600 × 1200 resolution |
| Eyepiece specifications | 25 mm eye relief; 12 mm exit pupil; -4 to +4 D dioptre adjustment |
| Interpupillary adjustment | Adjustable eyepiece spacing. Adjustment range: Not specified by manufacturer. |
| Viewing functions | Electronic image stabilisation; picture-in-picture; selectable palettes; Ultra-clear mode |
| Image calibration | Automatic and manual calibration; shutter and background calibration; pixel defect correction |
| Laser rangefinder | 1000 m measuring range; Class 1; single and continuous ranging |
| Rangefinder accuracy and wavelength | Not specified by manufacturer. |
| Ballistic calculation | Supported |
| Recording and storage | 64 GB internal memory; JPEG photographs; MP4 video; microphone; onboard gallery |
| Wireless connectivity | Wi-Fi; Bluetooth-assisted app connection; NocPix app support; N-Link image and range data sharing |
| Controls | Four buttons; separate thermal and digital focus wheels; central digital zoom ring; app customisation of selected buttons |
| IR illuminator compatibility | Interchangeable 850 nm and 940 nm IR illuminators; illuminator not included with L19R |
| Battery system | Built-in battery plus two replaceable 18650 batteries; removable cells support insertion in either polarity orientation |
| Maximum operating time | 7.5 hours at 22°C; actual duration depends on use of functions including Wi-Fi, video recording and IR illumination |
| External power and charging | 5 V USB-C input; internal battery charging through the device; removable 18650 batteries require a separate charger |
| Housing and mounting | Magnesium-alloy housing; PVC grip surfaces; 1/4-20 UNC tripod connection |
| Ingress protection | IP67 |
| Operating temperature | -20°C to +50°C |
| Weight | <900 g without batteries |
| Dimensions | <198 × 144 × 75 mm |
| Specification | Details |
|---|---|
| Model | NocPix Omni H35R |
| Imaging channels | Thermal imaging and digital day/night vision |
| Thermal detector | 640 × 512 pixels; 12 μm pixel pitch |
| Thermal sensitivity | NETD ≤15 mK |
| Frame rate | Thermal: 50 Hz; digital: 50 Hz |
| Thermal objective lens | 35 mm F0.9 |
| Thermal magnification | 2×–16× |
| Thermal field of view | 12.5° × 9.4°; 21.9 × 16.5 m at 100 m (horizontal × vertical) |
| Thermal detection range | 1800 m for a 1.7 × 0.5 m target, P(n)=99% |
| Digital detector | 8192 × 6144 pixels; 1.2 μm pixel pitch |
| Digital objective lens | 50 mm F1.8 |
| Digital magnification | 3×–18× |
| Digital field of view | 8.8° × 6.6°; 15.4 × 11.5 m at 100 m (horizontal × vertical) |
| Digital detection range | 1000 m for a 1.7 × 0.5 m target, P(n)=99% |
| Low-light colour imaging and dynamic range | Colour imaging down to 0.001 lux; 140 dB dynamic range |
| Display | 0.5-inch AMOLED; 1600 × 1200 resolution |
| Eyepiece specifications | 25 mm eye relief; 12 mm exit pupil; -4 to +4 D dioptre adjustment |
| Interpupillary adjustment | Adjustable eyepiece spacing. Adjustment range: Not specified by manufacturer. |
| Viewing functions | Electronic image stabilisation; picture-in-picture; selectable palettes; Ultra-clear mode |
| Image calibration | Automatic and manual calibration; shutter and background calibration; pixel defect correction |
| Laser rangefinder | 1000 m measuring range; Class 1; single and continuous ranging |
| Rangefinder accuracy and wavelength | Not specified by manufacturer. |
| Ballistic calculation | Supported |
| Recording and storage | 64 GB internal memory; JPEG photographs; MP4 video; microphone; onboard gallery |
| Wireless connectivity | Wi-Fi; Bluetooth-assisted app connection; NocPix app support; N-Link image and range data sharing |
| Controls | Four buttons; separate thermal and digital focus wheels; central digital zoom ring; app customisation of selected buttons |
| IR illumination | Removable 850 nm illuminator supplied; low, medium and high output settings; compatible with interchangeable 850 nm and 940 nm illuminators |
| Battery system | Built-in battery plus two replaceable 18650 batteries; removable cells support insertion in either polarity orientation |
| Maximum operating time | 7.5 hours at 22°C; actual duration depends on use of functions including Wi-Fi, video recording and IR illumination |
| External power and charging | 5 V USB-C input; internal battery charging through the device; removable 18650 batteries require a separate charger |
| Housing and mounting | Magnesium-alloy housing; PVC grip surfaces; 1/4-20 UNC tripod connection |
| Ingress protection | IP67 |
| Operating temperature | -20°C to +50°C |
| Weight | <900 g without batteries |
| Dimensions | <198 × 144 × 75 mm |
