Part of the Tube Series, the TH35 is the bigger brother of the TL35. Designed to be a “one can do all” solution, the TH35 is equipped with a 464x464/12µm sensor, 35mm objective lens and 1.39" OLED display, allowing the user to detect targets up to 1,816 meters while utilizing the sight’s 3.00 to 9.00 times magnification. The TH35 is best suited for those seeking a full feature picatinny-mounted sight in a traditional 30mm scope form factor but require increased performance over the TL35 and/or prefer a circular display.
The Tube Series is designed for faultless operation in extreme weather and temperature conditions. Whether or not the environment is freezing cold or blistering hot, the image retains its contrast and vivid colors without loss of frame rate.
The application of 1.39’round screen is groundbreaking and Innovative in the thermal scope industry. The grand view brought by 1.39’round screen can present a more comfortable and pleasant observing experience.
32 GB internal storage provides hours of video recording capability, or thousands of images of photo storage. WiFi mode allows for up to 4 connections simultaneously.
When Ultraclear mode is on, bad weather condition effect is off. With Untraclear mode, TH35 can still provide a clear and detailed image even in bad weather conditions such as heavy fog and rain. Bad weather can’t slow you down .
The Tube series housing is made of aluminum and is designed to improve reliability. Designed for rugged reliability, Tube riflescopes boast full, reinforced yet lightweight metal construction. Precision-fabrication of housing elements ensures flawless field performance.
Applicable for 30mm diameter pipe, the newly designed tubular appearance allows the Tube series to be installed on standard 30mm scope rings, with simple operation, stability and reliability.
Built-in batteries work for 8 hours, and with an additional 18500 battery for back up, working time of TH35 will be 11.5 hours
While TH35 can achieve the magnification of 3.0-9.0 times, it can perform infinite zooming which means you can adjust the magnification to the times you like during 3.0-9.0. Fit your need more by serving the details in a way you want it to.
WARRANTY INFO: Standard 3-year warranty from Infiray Canada
Main Features
Specs
| Detector Resolution | 464x464 |
| Pixel Pitch | 12um |
| NETD, mK | <=40 |
| Frame Rate | 50Hz |
| Objective Lens Diameter | 35mm |
| FOV | 8.8 |
| Magnification | 3-9x |
| Eye Relief | 50mm |
| Detection range | 1816m |
| Display | 1.39" OLED |
| Battery | 2x 18650 (built-in) |
| Optional Battery | 18500 |
| Battery Life | 11.5h |
| Weight | <850g |
| Dimensions | 375x85x75mm |
| USB interface | USB-C |
| Internal Storage | 32GB |
Full Manual HERE.
What's in the box:
